KONE BED / STRETCHER LIFTS – Designed for hospitals
In modern healthcare facilities, LIFTS need to move patients and staff smoothly and safely.
KONE offers a full range of specially developed BED LIFTS for optimum performance in the highly demanding environment of patient transportation.
For your maximum safety we take all the necessary measures. Your safety is our primary concern.
Note:
- Typically BED / STRETCHER LIFTS can be planned to accommodate an attendant and a stretcher or a bed
or a bed with a trolley. Based on the need, the right size of the car has to be chosen. - Where wheel chairs are used and there is a need to turn the wheel chair inside the LIFT car, a minimum width of 1525 mm is recommended.
LIFT Model | Rated Speed (m/s) | Number of persons | Load [kg] | Car Width BB [mm] | Car Depth DD [mm] | Door Opening LL [mm] | Shaft Width WW [mm] | Shaft Depth WD [mm] |
---|---|---|---|---|---|---|---|---|
BT10 | 1.0 & 1.6 | 15 | 1020 | 1000 | 2400 | 800 / 900 | 1775 | 2950 |
BT14 | 1.0 & 1.6 | 20 | 1360 | 1300 | 2400 | 1000 / 1100 / 1200 | 2125 / 2125 / 2200 | 2950 |
BT18 | 1.0 & 1.6 | 25 | 1768 | 1600 | 2400 | 1000 / 1100 / 1200 | 2425 | 2950 |
Some of our BED / STRETCHER LIFT clients in Bangladesh:
BIRDEM HOSPITAL | LAB AID GROUP
